Ashdown EvoII 300

Power & Performance
Power Output (RMS): 307 Watts
Power Requirement: 230 / 115V
Speaker Outputs: Minimum 4 Ohms (2 x Jack sockets)
Frequency Response: -3dB at 17Hz and 30KHz
Signal to Noise: Better than 80dB (EQ flat)
Distortion: Less than 0.5% THD
Gear4music
Gear4music
+1
Preamp & EQ
EQ Section: 5-band rotary EQ (Bass, Lo-Mid, Middle, Hi-Mid, Treble)
EQ Boost/Cut: +/-15dB
EQ Frequencies:
Bass: 100Hz
Lo-Mid: 220Hz
Middle: 660Hz
Hi-Mid: 1.6kHz
Treble: 7kHz shelving
Shape/Filters: 'Deep' (+8dB @ 50Hz) and 'Bright' (+10dB @ 10kHz) switches
Sub-Harmonic Generator: Included (octaver)
Compressor: Built-in
Ashdown Engineering
Ashdown Engineering
+1
Inputs & Outputs
Instrument Inputs: High/Low impedance
Line Input/Output: Gear4music.com lists 22k Ohms input/output
DI Output: 600 Ohms balanced
Effects Loop: Included
Gear4music
Gear4music
Physical & Construction
Dimensions/Weight: ~90 x 463 x 267 mm, 12.5 kg
Cooling: Fan-cooled
